Dimensions

4X4 specifics
16.7 degree maximum slope approach angle and 23.9 degree maximum slope departure angle
External dimensions
External dimensions: 4,480mm long, 1,855mm wide, 1,635mm high, 172mm ground clearance, 2,670mm wheelbase, 1,613mm front track, 1,625mm rear track, 10,600mm turning circle (wall to wall), 176.4 inches long, 73.0 inches wide, 64.4 inches high, 6.8 inch grou
Fuel tanks
62 litre, 13.6 UK gallon main fuel tank
Internal dimensions
Internal dimensions: front headroom (mm): 997, front headroom (inches): 39.3, rear headroom (mm): 993, rear headroom (inches): 39.1, front leg room (mm): 1,129, front leg room (inches): 44.4, rear leg room (mm): 970 and rear leg room (inches): 38.2
Load compartment capacity
Load compartment capacity: 491 litres with rear seats up filled to lower edge of window, 1,480 litres with rear seats down filled to ceiling, 17.3 cu ft with rear seats up filled to lower edge of window and 52.3 cu ft with rear seats down filled to ceilin
Ramp angles
16.7 degree maximum slope approach angle and 23.9 degree maximum slope departure angle
Weights
Weights: Kerb weight (kg): 1,500, Kerb weight (lbs): 3,307, Kerb weight includes driver, Gross vehicle weight rating (kg): 2,190, Gross vehicle weight rating (lbs): 4,828, Gross trailer weight braked (kg): 1,400, Gross trailer weight braked (lbs): 3,086,

Exterior

Aerial
Aerial
Bumpers
Front and rear bumpers
Chrome/bright trim
Chrome/bright trim around side windows
Day time running lights
Day time running lights
Door mirrors/cameras
Body colour power door mirrors ; heated with integrated indicator lights
Electrically foldable mirrors
Electrically foldable mirrors
Front fog lights
Front fog lights
LED lights
LED day time running lights
Paint
Metallic paint
Rear windscreen
Rear windscreen with intermittent wiper
Roof rails
Roof rails
Spare wheel
Space saver steel spare wheel
Spoiler
Roof spoiler
Tinted glass
Tinted glass
Tyres
Front and rear tyres: 17 inch diameter, 225mm wide, 60% profile, H rated ; Load index: 99 (official data)
Wheels
Front and rear wheels: 17 inch alloy rims ; width: 6.5 inches
Windscreen wipers
Rain sensing windscreen wipers

Interior

12v power outlet
12v power outlet located in cargo section, front section and rear section
Air conditioning
Automatic air conditioning with two climate control zones
Audio player
Audio system with touch screen ; radio receives AM/FM, digital and RDS colour screen
Bluetooth
Bluetooth includes phone connection and music streaming
Central door locking
Central door locking: Operated by remote Includes dead bolt
Computer
Computer includes average speed, average fuel consumption, instantaneous fuel consumption and range for remaining fuel
Connection to ext.entertainment devices
Connections for USB (front) and auxiliary audio devices (front)
Console
Floor console, partial overhead console
Cup holders
Cup holders for front seats and rear seats
Display screen
Single 7.0 inch touch sensitive multi-function display screen(s)
Doors
Front hinged drivers door, rear door on drivers side, front passenger door and rear door on passenger side
Dynamic steering
Dynamic steering
Electric windows
Front electric windows with one-touch on one window, rear electric windows
External temperature
External temperature
Floor mats
Floor mats
Front seat
Driver seat: individual type, electrically adjustable, one electrical adjustment, passenger seat: individual type
Front seat centre armrest
Centre armrest between front seats
Instrument cluster
Analogue & TFT dashboard
Instrument panel
Analogue & TFT dashboard
Load area light
Load area light
Load restraint
Load restraint
Luxury trim
Leather gearknob
Multi-function display screen
Single 7.0 inch touch sensitive multi-function display screen(s)
Navigational systems
Satellite navigation system with colour, 7.0 inch display, touch screen, 3D and voice, maps updated via SD Card and traffic information
Privacy glass
Privacy glass on the rear window and on the rear side windows
Reading lights
Front reading lights
Rear door
Lifting gate rear door
Rear seat centre armrest
Centre armrest between rear seats
Rear seats
Asymmetrically folding rear seats: bench type with space for three people; with zero electric adjustments
Rear view mirror
Light sensitive rear view mirror
Rear view mirror/camera
Light sensitive rear view mirror
Remote audio controls
Steering wheel mounted remote audio controls
Remote boot/hatch/rear door release
Remote controlled remote boot/hatch/rear door release
Seat upholstery
Seat upholstery: upgraded cloth/velour and upgraded cloth/velour
Seating
Five seats configured 2+3
Secondary ventilation controls
Secondary ventilation controls with digital display for front passenger
Speakers
Six speakers
Start/Stop
Engine start/stop
Steering wheel
Leather covered multi-function steering wheel with tilt adjustment and telescopic adjustment
Tachometer
Tachometer
Vanity mirror
Illuminated driver and passenger vanity mirror
Ventilation system
Ventilation system with digital display and air filter

Others

Airbags
Six airbags
Apps control
Apps control
Body style
Five door sports utility vehicle ; Right hand drive
Built-in Apps
Built-in Apps
Cargo area cover/rear parcel shelf
Flexible cargo area cover/rear parcel shelf
Charges
Charges: VAT [20%] = 3,655.83, VED (Standard Rate) = 140.00, FRF = 55.00, VED (First Year 111 - 130 g/km) = 160.00, Additional Charges (GB) = 0.00
Data completeness
Data completeness: up to date pricing data, up to date data for key leasing items, specifications data from official documentation, up to date colour & trim data, up to date option pricing data, up to date option content data and up to date incentives dat
Date introduced
Date introduced: Model introduced 02 Feb 2016 and Version introduced 02 Feb 2016
Delivery charges
Fixed delivery charges: 595.00, 495.83 (excluding VAT) fuel included 0 litres includes number plates
Global segment
Global segment
Insurance
Insurance
Mobile Integration
Mobile Integrationusing Apple CarPlay and Android Auto
Navigation via mobile phone
Navigation via mobile phone
Regional segment
Regional segment
Seat belt warning
Seat belt warning on five seats
Text to speech / speech to text
Text to speech / speech to text
Traffic sign recognition
Traffic sign recognition
Trim
2 trim level - JATO classification: M2
Warranty anti-corrosion
Anticorrosion warranty: 120 months, 100,000 miles, 160,934 km
Warranty paint
Paint warranty: 60 months, 100,000 miles, 160,934 km
Warranty powertrain - OEM
Manufacturers powertrain warranty: 84 months, 160,934 km, 100,000 miles
Warranty powertrain - Total
Powertrain warranty: 84 months, 100,000 miles, 160,934 km
Warranty roadside assistance
Road-side assistance warranty: 12 months, Unlimited miles, Unlimited km
Warranty whole vehicle - OEM
Manufacturers whole vehicle warranty: 84 months, 160,934 km, 100,000 miles
Warranty whole vehicle - Total
Vehicle warranty: 84 months, 100,000 miles, 160,934 km

Safety

ABS
ABS
Automatic hazard lights
Automatic hazard lights
Brake assist system
Brake assist system
Cornering brake control
Cornering brake control
Crash test results
Euro NCAP crash test results: Overall: 5.00, Adult occupant: 90.00, Child occupant: 83.00, Pedestrian: 66.00, Safety assist: 71.00, Version tested: Kia Sportage 1.7 diesel GL 5dr OD, Date tested: 02 Dec 2015
Disc brakes
Four disc brakes including two ventilated discs
Electronic brake distribution
Electronic brake distribution
Electronic traction control
Electronic traction control
Front airbag
Intelligent drivers airbag, intelligent passengers airbag with de-activation switch
Front seat belts
Height adjustable seat belt with pre-tensioners on drivers seat and front passenger seat
Head restraints
Two active head restraints on front seats with height adjustment, three head restraints on rear seats with height adjustment
Headlight control
Headlight controlsystems: dusk sensor, on-coming vehicle sensor and automatic height adjustment
Headlights
Halogen low beam halogen high beam headlights with ellipsoidal lenses
Isofix preparation
Isofix preparation
Lane departure warning
Lane departure warningsystem activates steering
Low tyre pressure indicator
Low tyre pressure indicator with rim mounted sensor displays pressure
Parking distance sensors
Rear radar & camera-type parking distance sensors
Parking distance system
Rear radar & camera-type parking distance sensors
Rear seat belts
Seat belt on driver side rear seat, seat belt on passenger side rear seat, 3-point seat belt on central rear seat
Side airbag
Front side airbag
Side curtain airbag
Front and rear side curtain airbags
Stability control
Stability controlsystem
Trailer stability program
Trailer stability program

Security

Anti-theft protection
Anti-theft protection with interior monitoring

Technical

Compressor
Turbo-charger
Cruise control
Cruise control
Drive
Front-wheel drive with descent control
Emission control level
Emissions: EU6 compliant and 119 g/km CO2 (max)
Energy recuperation
Energy recuperation
Engine
1,685 cc 1.7 litres in-line 4 engine with 77.2 mm bore, 90.0 mm stroke, 17.0 compression ratio, variable valve timing/camshaft and four valves per cylinder
Fuel
Primary fuel type: diesel
Fuel consumption
Fuel consumption: 5.4 l/100km (urban), 4.2 l/100km (country/highway), 4.6 l/100km (combined), 44 mpg (urban US), 56 mpg (country/highway US), 51 mpg (combined US), 18.5 km/l (urban), 23.8 km/l (country/highway), 21.7 km/l (combined), 52 mpg (urban UK), 67
Fuel system
Fuel system: common rail diesel
Hill holder
Hill holder
Main service
Main service required after 32,187 km, 20,000 miles, 12 months
Particle filter system
Particle filter system
Performance
Performance: maximum speed 109 mph, 175 km/h acceleration 11.5 seconds (0-100 km/h)
Power
Power: (from primary fuel) 84 kW , 114 HP EEC @ 4,000 rpm; , 280 Nm @ 1,250 rpm
Power steering
Power steering: type speed proportional
Powertrain
Powertrain: internal combustion engine
Powertrain type
Powertrain: internal combustion engine
Speed limiter
Speed limiter
Suspension
Independent strut front suspension with anti-roll bar and coil springs, independent multi-link rear suspension with anti-roll bar and coil springs
Transmission
Transmission: 6-speed manual featuring gear lever mounted on the floor
